Jaguar av to genesis-2-av
About the Jaguar av to genesis-2-av PCB
Jaguar av to genesis-2-av is an open source PCB design by barbeque, published on GitHub under the MIT license. It is a 2-layer board measuring 30.5 × 24.4 mm, with 2 components from 2 distinct parts.
From the project
An adapter board to use Genesis 2 AV/RGB cables on an Atari Jaguar
RGB has been confirmed to work, with the Insurrection Industries SCART cable. See the "Known Issues" section below for some caveats.
It was developed as part of a Leaded Solder blog entry.
You can import the BOM using the included CSV file.
+5VDC is not generated from the Jaguar's +9VDC, so if your upscaler, television, or cables depend on the presence of the +5V pin in order to work (e.g. SCART) the output will not be detected. S-Video is not yet tested.
Jaguar av to genesis-2-av bill of materials (BOM)
2 components, 2 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | JaguarAV_24 | JaguarAV_24p | J1 |
| 1 | Genesis2AV | CUI_MD-90S | J2 |
Jaguar av to genesis-2-av design files
The KiCad project lives in the barbeque/jaguar-av-to-genesis-2-av repository on GitHub; these links point at the commit this page was built from.
Jaguar av to genesis-2-av: common questions
How big is the Jaguar av to genesis-2-av PCB?
The Jaguar av to genesis-2-av measures 30.5 × 24.4 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Jaguar av to genesis-2-av?
2 components, from 2 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the Jaguar av to genesis-2-av design files?
From the barbeque/jaguar-av-to-genesis-2-av repository on GitHub, which has the KiCad layout and the BOM; the links under Design files point to each one.
Can I use the Jaguar av to genesis-2-av design in my own project?
Yes, under the terms of its MIT license, which barbeque chose for the repository.
