Envoy-Backplate
About the Envoy-Backplate PCB
Envoy-Backplate is an open source PCB design by JeJeff, published on GitHub. It is a 2-layer board measuring 95.4 × 95.4 mm, with 6 components from 2 distinct parts.
It belongs with the keyboards designs in this gallery.
From the project
Numberpad with encoders
Envoy-Backplate bill of materials (BOM)
6 components, 2 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 4 | BumperPad | BumperLocator_8.5mm | B1, B2, B3, B4 |
| 2 | MountingHole | Keyboard_conical_foot | H5, H6 |
Envoy-Backplate design files
The KiCad project lives in the JeJeff/Envoy repository on GitHub; these links point at the commit this page was built from.
Envoy-Backplate: common questions
How big is the Envoy-Backplate PCB?
The Envoy-Backplate measures 95.4 × 95.4 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Envoy-Backplate?
6 components, from 2 distinct parts. The full bill of materials is listed on this page.
Where can I download the Envoy-Backplate design files?
From the JeJeff/Envoy repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.
Can I use the Envoy-Backplate design in my own project?
The repository has no license, so all rights stay with JeJeff. Use it as a reference, and ask the author before reusing the design.
