Om27 strumplate
About the Om27 strumplate PCB
Om27 strumplate is an open source PCB design by keyandcableco, published on GitHub. It is a 2-layer board measuring 112.1 × 159.1 mm, with 0 components from 0 distinct parts.
From the project
Strumplate Reproductions for Suzuki Omnichords
This project is an effort to reproduce the strumplate for the Suzuki Omnichord. It started with the OM-84 because that's what we had on hand, and now also covers the OM-27.
- om84strumplate/ — OM-84 work (flex PCB design, gerbers, references) - om27strumplate/ — OM-27 work (in progress)
The Omnichord strumplate is a large capacitive touch sensor that lets you strum chords. Over time these plates commonly fail — the conductive surface wears out, traces crack, or sections stop responding.
Om27 strumplate design files
The KiCad project lives in the keyandcableco/Omnichord-Strumplates repository on GitHub; these links point at the commit this page was built from.
Om27 strumplate: common questions
How big is the Om27 strumplate PCB?
The Om27 strumplate measures 112.1 × 159.1 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Om27 strumplate?
0 components, from 0 distinct parts. The full bill of materials is listed on this page.
Where can I download the Om27 strumplate design files?
From the keyandcableco/Omnichord-Strumplates repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.
Can I use the Om27 strumplate design in my own project?
The repository has no license, so all rights stay with keyandcableco. Use it as a reference, and ask the author before reusing the design.
