Bandgap-Reference-Circuit
About the Bandgap-Reference-Circuit PCB
Bandgap-Reference-Circuit is an open source PCB design by Knavere29, published on GitHub under the GPL-3.0 license. It is a board, with 17 components from 4 distinct parts.
By type, the board carries 9 transistors, 5 modules and 3 resistors.
From the project
Bandgap Reference Circuit using IHP 130nm BiCMOS Open Source PDK and eSim
The variables are set during the IHP open PDK installation steps. Proceed further if the tool installation and path variable checking are successful. ### STEP1: Open the terminal and clone the git repository. Then change the working directory.
Alternately, simulation plots can be opened manually using a file browser.
Bandgap-Reference-Circuit bill of materials (BOM)
17 components, 4 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 4 | eSim_MOS_P | M1, M3, M4, M5 | |
| 1 | eSim_MOS_N | M2 | |
| 9 | eSim_NPN | Q1, Q2, Q3, Q4, Q5, Q6, Q7, Q8 +1 | |
| 3 | ${SIM.PARAMS} | R1, R2, R3 |
Bandgap-Reference-Circuit design files
The KiCad project lives in the Knavere29/Bandgap-Reference-Circuit repository on GitHub; these links point at the commit this page was built from.
- Schematicbgr/bgr.kicad_sch
Bandgap-Reference-Circuit: common questions
How many components are on the Bandgap-Reference-Circuit?
17 components, from 4 distinct parts. The full bill of materials is listed on this page.
Where can I download the Bandgap-Reference-Circuit design files?
From the Knavere29/Bandgap-Reference-Circuit repository on GitHub, which has the schematic; the links under Design files point to each one.
Can I use the Bandgap-Reference-Circuit design in my own project?
Yes, under the terms of its GPL-3.0 license, which Knavere29 chose for the repository.
