HDMI-A2C
About the HDMI-A2C PCB
HDMI-A2C is an open source PCB design by likeablob, published on GitHub under the MIT license. It is a 2-layer board measuring 25 × 16 mm, with 3 components from 2 distinct parts.
From the project
A simple HDMI A to HDMI C adapter board (KiCad).
HDMI-A2C bill of materials (BOM)
3 components, 2 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | HDMI_A | HDMI_A_HDP19-017_Horizontal | J1 |
| 2 | HDMI_C_1.3 | HDMI_C_MH-02PLG_Horizontal | J2, J3 |
HDMI-A2C design files
The KiCad project lives in the likeablob/HDMI-A2C repository on GitHub; these links point at the commit this page was built from.
- Layouthdmi-a2c.kicad_pcb
HDMI-A2C: common questions
How big is the HDMI-A2C PCB?
The HDMI-A2C measures 25 × 16 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the HDMI-A2C?
3 components, from 2 distinct parts. The full bill of materials is listed on this page.
Where can I download the HDMI-A2C design files?
From the likeablob/HDMI-A2C repository on GitHub, which has the KiCad layout; the links under Design files point to each one.
Can I use the HDMI-A2C design in my own project?
Yes, under the terms of its MIT license, which likeablob chose for the repository.
