Guitar Pedal

lucacros·GuitarePedal_2324Project·Electronic_Board_V1.0/EC.kicad_pcb

Guitar Pedal PCB layout, top view — open source STM32 board by lucacros

About the Guitar Pedal PCB

Guitar Pedal is an open source STM32 PCB design by lucacros, published on GitHub. It is a 6-layer board measuring 169 × 103.5 mm, with 109 components from 24 distinct parts.

Its main chip is the STM32F446ZCTx, from the STM32 family. Other key parts include the BU33SD5WG-TR, BU18SD2MG-MTR, IS42S16400J-xC and SGTL5000XNAA3. By type, the board carries 47 capacitors, 26 test points, 9 connectors, 7 resistors, 6 ICs and 4 diodes.

It belongs with the audio designs in this gallery.

From the project

Projet de 2ème année à l'ENSEA, création d'une pédale de guitare. CROSETTO Luca / THOMASSET Jolan / LANFREDI Camille

Hello music and technology fans! Welcome to the GitHub showcase for our multi-effects guitar pedal project. Here you'll find details, tools, and resources related to this exciting project. This is an academic project completed in 100 hours by the legendary trio: Luca CROSETTO, Jolan THOMASSET, and Camille LANFREDI

- 📌 Présentation - 📅 Management Section - 🛠️ Hardware Section - 💻 Software Section - 🚀 Contributions - 📜 Licence

Guitar Pedal, from the project README
From the project README

Main components on the Guitar Pedal

BU33SD5WG-TRBU18SD2MG-MTRIS42S16400J-xCSTM32F446ZCTxSGTL5000XNAA3

Guitar Pedal bill of materials (BOM)

109 components, 24 distinct parts.

QtyPartRefs
2
BU33SD5WG-TR
U1, U2
1
BU18SD2MG-MTR
U3
1
IS42S16400J-xC
U4
1
STM32F446ZCTx
U6
1
SGTL5000XNAA3
U7
4
NMJ4HCD2
J1, J4, J5, J6
1
4840.2201 power connector
J2
1
173950578
J3
2
Conn_01x03
J7, J9
1
Conn_02x07_Odd_Even
J8
10
100k
RV1, RV2, RV3, RV4, RV5, RV6, RV7, RV8 +2
26
TestPoint
TP1, TP2, TP3, TP4, TP5, TP6, TP7, TP8 +18
2
RED
D1, D3
2
LED
D2, D4
1
100uF
C1
1
100µF
C2
6
1uF
C3, C4, C5, C6, C7, C8
36
100nF
C9, C10, C11, C12, C13, C14, C15, C20 +28
1
4.7u
C17
2
2.2uF
C18, C19
Show 4 more
QtyPartRefs
2
1k
R1, R2
2
330
R3, R4
2
1.5k
R5, R7
1
510
R6

Guitar Pedal design files

The KiCad project lives in the lucacros/GuitarePedal_2324Project repository on GitHub; these links point at the commit this page was built from.

Guitar Pedal: common questions

What microcontroller does the Guitar Pedal use?

The Guitar Pedal is built around the STM32F446ZCTx, from the STM32 family.

How big is the Guitar Pedal PCB?

The Guitar Pedal measures 169 × 103.5 mm, has 6 copper layers and is 1.6 mm thick.

How many components are on the Guitar Pedal?

109 components, from 24 distinct parts. The full bill of materials is listed on this page.

Where can I download the Guitar Pedal design files?

From the lucacros/GuitarePedal_2324Project repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the Guitar Pedal design in my own project?

The repository has no license, so all rights stay with lucacros. Use it as a reference, and ask the author before reusing the design.

Can I test firmware for the Guitar Pedal without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug STM32 firmware against it before you order a PCB.
