Mixed signal design
About the Mixed signal design PCB
Mixed signal design is an open source PCB design by MahimaGoyen, published on GitHub. It is a board, with 25 components from 7 distinct parts.
Other key parts include the mahima_decoder, adc_bridge_4, dac_bridge_8 and plot_v1. By type, the board carries 11 ICs and 8 crystals.
Main components on the Mixed signal design
Mixed signal design bill of materials (BOM)
25 components, 7 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | mahima_decoder | U1 | |
| 1 | adc_bridge_4 | U2 | |
| 1 | dac_bridge_8 | U3 | |
| 8 | plot_v1 | U4, U5, U6, U7, U8, U9, U10, U11 | |
| 8 | Mahima_1bitRAM | X1, X2, X3, X4, X5, X6, X7, X8 | |
| 5 | pulse | R1 | v1, v2, v3, v5, v6 |
| 1 | DC | R1 | v4 |
Mixed signal design design files
The KiCad project lives in the MahimaGoyen/Mixed_signal_design repository on GitHub; these links point at the commit this page was built from.
Mixed signal design: common questions
How many components are on the Mixed signal design?
25 components, from 7 distinct parts. The full bill of materials is listed on this page.
Where can I download the Mixed signal design design files?
From the MahimaGoyen/Mixed_signal_design repository on GitHub, which has a netlist; the links under Design files point to each one.
Can I use the Mixed signal design design in my own project?
The repository has no license, so all rights stay with MahimaGoyen. Use it as a reference, and ask the author before reusing the design.
