Kicad gen
About the Kicad gen PCB
Kicad gen is an open source PCB design by matialegre, published on GitHub under the MIT license. It is a board, with 4 components from 2 distinct parts.
By type, the board carries 2 diodes and 2 resistors.
From the project
Generate KiCad 10 schematics from Python code and verify them with kicad-cli (ERC 0/0, text-overlap QA, PDF/netlist/BOM/PNG)
Generate KiCad 10 schematics from Python code, and verify them with kicad-cli. Esquemáticos de KiCad 10 generados por código Python y verificados con kicad-cli. Castellano abajo.
You write the schematic as a Python script: explicit coordinates, real wires, power rails as power symbols, hierarchical sheets. The script writes plain .kicadsch` files that open in KiCad like any hand-drawn schematic, and a verification pipeline runs the ERC with every severity enabled, checks for overlapping text, and exports PDF, netlist, BOM and PNG. Same input, same file, byte for byte (deterministic UUIDs)…
Kicad gen bill of materials (BOM)
4 components, 2 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 2 | LED_VERDE | LED_D5.0mm | D101, D201 |
| 2 | 330 | R_Axial_DIN0207_L6.3mm_D2.5mm_P10.16mm_Horizontal | R101, R201 |
Kicad gen design files
The KiCad project lives in the matialegre/kicad-gen repository on GitHub; these links point at the commit this page was built from.
- Schematicejemplo/modulo_led.kicad_sch
Kicad gen: common questions
How many components are on the Kicad gen?
4 components, from 2 distinct parts. The full bill of materials is listed on this page.
Where can I download the Kicad gen design files?
From the matialegre/kicad-gen repository on GitHub, which has the schematic; the links under Design files point to each one.
Can I use the Kicad gen design in my own project?
Yes, under the terms of its MIT license, which matialegre chose for the repository.
