CLKGEN02

mlab-modules·CLKGEN02·hw/sch_pcb/CLKGEN02.kicad_pcb

CLKGEN02 PCB layout, top view — open source board by mlab-modules

About the CLKGEN02 PCB

CLKGEN02 is an open source PCB design by mlab-modules, published on GitHub. It is a 2-layer board measuring 19.8 × 40.1 mm, with 17 components from 15 distinct parts.

By type, the board carries 8 crystals, 3 connectors, 3 capacitors, 2 resistors and 1 diode.

From the project

The module comprises a plurality of housings for mounting a variety of crystal oscillators.

Universal module for crystal oscillators

The module comprises a plurality of housings for mounting a variety of crystal oscillators.

CLKGEN02, from the project README
From the project README

CLKGEN02 bill of materials (BOM)

17 components, 15 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
ASFL1, ASFLK
X1
1
CFPS-72,CFPS-73
X2
1
ISM92
X3
1
ISM97
X4
1
I533_I534_I733_I734_SERIES
I533_I534_I733_I734_Series
X6
1
ISM81
X7
1
ISM95
X8
1
OSC-F
X9
2
JUMP_3X2
J1, J3
1
JUMP_2X1
JUMP_2x1
J2
1
BZV55C
D1
1
10NF
10nF
C1
1
100NF
100nF
C2
1
10UF
10uF
C3
2
R
R1, R2

CLKGEN02 design files

The KiCad project lives in the mlab-modules/CLKGEN02 repository on GitHub; these links point at the commit this page was built from.

CLKGEN02: common questions

How big is the CLKGEN02 PCB?

The CLKGEN02 measures 19.8 × 40.1 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the CLKGEN02?

17 components, from 15 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the CLKGEN02 design files?

From the mlab-modules/CLKGEN02 repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the CLKGEN02 design in my own project?

The repository has no license, so all rights stay with mlab-modules. Use it as a reference, and ask the author before reusing the design.
