Coils
About the Coils PCB
Coils is an open source PCB design by sirlilpanda, published on GitHub. It is a 2-layer board measuring 83 × 83 mm, with 0 components from 0 distinct parts.
From the project
a repo for storing PCB based emat designs
a cool table showing the workflow of all the kicad projects. | project_name | DRC | ERC | | ------------ | --- | --- | | template | ❌| ✅ |
This is a simple project template for new kicad projects. This template has some basic setup already completed such as workflows for auto creating all the things you forget when creating a kicad project such as:
This workflow will also run the design rules check on the PCB and schematic to ensure that you upload a working PCB. These reports are uploaded as summaries within the github actions tab. This template has a simple schematic PCB in it (because…
