The-SaxCardTM
About the The-SaxCardTM PCB
The-SaxCardTM is an open source PCB design by tenorangesax, published on GitHub. It is a 2-layer board measuring 92.2 × 52.7 mm, with 5 components from 5 distinct parts.
By type, the board carries 1 antenna, 1 LED, 1 capacitor and 1 resistor.
From the project
A simple PCB business card that anyone can use! That's literally it.
THE FINAL PRODUCT! (censored because personal information...)
https://github.com/user-attachments/assets/a923748c-2b25-4671-bdd0-5f281c965b37
I went into NFC tools (app) and made it so it the NFC redirects to my Github page and the LED blinks.
I cleaned up the repo for it and attached a video of it working, along with all pictures and videos. I'm really proud of this project, because of the little details I made, like my name and position being shiny instead of a regular silkscreen, and the QR codes and info on the back with the eye-blinking LED.
The-SaxCardTM bill of materials (BOM)
5 components, 5 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | 25X48MM_NFC_ANTENNA | 25X48MM_NFC | ANT0 |
| 1 | NT3H | XQFN8 | NT3H1101 |
| 1 | — | SML0805_259 | LED1 |
| 1 | 220 nf | C0603_348 | C1 |
| 1 | 47 Ω | R0603_348 | R1 |
The-SaxCardTM design files
The KiCad project lives in the tenorangesax/The-SaxCardTM repository on GitHub; these links point at the commit this page was built from.
- LayoutPRODUCTION/SaxCard.kicad_pcb
- SchematicPRODUCTION/SaxCard.kicad_sch
The-SaxCardTM: common questions
How big is the The-SaxCardTM PCB?
The The-SaxCardTM measures 92.2 × 52.7 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the The-SaxCardTM?
5 components, from 5 distinct parts. The full bill of materials is listed on this page.
Where can I download the The-SaxCardTM design files?
From the tenorangesax/The-SaxCardTM repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.
Can I use the The-SaxCardTM design in my own project?
The repository has no license, so all rights stay with tenorangesax. Use it as a reference, and ask the author before reusing the design.
