TXCompute is an open source PCB design by TXWD1234, published on GitHub under the MIT license. It is a 2-layer board measuring 22.5 × 30 mm, with 12 components from 4 distinct parts.
By type, the board carries 6 resistors, 5 transistors and 1 connector.
From the project
Better calculator that can handle complex logic. Project for hackathon: Fallout
TXCompute is a device to perform mathematical calculations. It is targeting to be a more powerful calculator, that don't only rely on buttons, but can handle complicated logic. This project is for the hackathon event Fallout hosted by Hackclub.
The input of user will be processed by a command line parser, which can handle simple commands, as well as TXCSL code. If user input is TXCSL code, it will be forward to the TXCSL engine, which executes the input code, and outputs the execution result.
TXCompute bill of materials (BOM)
12 components, 4 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 4 | 2N3904 | TO-92_Inline | Q24, Q25, Q26, Q27 |
| 1 | P-Channel MOSFET | TO-220-3_Vertical | Q28 |
| 1 | Conn_01x07_Pin | PinHeader_1x07_P2.54mm_Vertical | J1 |
| 6 | 10k | R_Axial_DIN0207_L6.3mm_D2.5mm_P7.62mm_Horizontal | R41, R42, R43, R44, R45, R46 |
