Kicad learning
About the Kicad learning PCB
Kicad learning is an open source PCB design by Yhass131, published on GitHub. It is a 2-layer board measuring 17 × 20 mm, with 12 components from 6 distinct parts.
Other key parts include the CAT4104VP2-GT3. By type, the board carries 4 LEDs, 3 capacitors, 3 resistors and 1 IC.
From the project
Working through KiCad from scratch — datasheet reading, custom symbols, custom footprints, and eventually full board layouts. Following Steppe School's tutorial playlist.
Working through KiCad from scratch — datasheet reading, custom symbols, custom footprints, and full board layouts, from schematic capture through fabrication files. Following Steppe School's KiCad tutorial playlist.
This repo is a public log of my progress: every component library, footprint, and board I build while learning, along with notes on what each step actually taught me.
Main components on the Kicad learning
Kicad learning bill of materials (BOM)
12 components, 6 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | CAT4104VP2-GT3 ~ onsemi | SOIC-8 | U1 |
| 1 | 10164359-00011LF ~ Amphenol ICC (FCI) | 10164359-00011LF | USB1 |
| 4 | 158301265A ~ Würth Elektronik | 158301265A | LED1, LED2, LED3, LED4 |
| 3 | GMC04X7R105K10NT 1u Cal-Chip Electronics, Inc. | C_0603_1608Metric | C1, C2, C3 |
| 1 | RMCF0603FT2K10 2k1 Stackpole Electronics Inc | R_0603_1608Metric | R1 |
| 2 | ERJ-3EKF5101V 5k1 Panasonic Industry | R_0603_1608Metric | R2, R3 |
Kicad learning design files
The KiCad project lives in the Yhass131/kicad-learning repository on GitHub; these links point at the commit this page was built from.
Kicad learning: common questions
How big is the Kicad learning PCB?
The Kicad learning measures 17 × 20 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Kicad learning?
12 components, from 6 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the Kicad learning design files?
From the Yhass131/kicad-learning repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.
Can I use the Kicad learning design in my own project?
The repository has no license, so all rights stay with Yhass131. Use it as a reference, and ask the author before reusing the design.
