BitDogLab Panel SMD version
About the BitDogLab Panel SMD version PCB
BitDogLab Panel SMD version is an open source PCB design by BitDogLab-Escola4-0, published on GitHub. It is a 2-layer board measuring 87.9 × 23.1 mm, with 11 components from 9 distinct parts.
From the project
Repositório dedicado a programação da BitDogLab que utiliza Linguagem MicroPython
BitDogLab, an initiative of the School Project 4.0 at Unicamp, is an educational tool devoted to electronics and computing. Based on Raspberry Pi Pico H or W, it allows users to explore, assemble, and program using components mounted on its board and also external ones connected in an organized and secure manner. Meticulously selected, the components foster hands-on learning, encouraging users to enhance programming and electronics skills synergistically and progressively. This enriching platform offers a vibrant experience, immersing users in a colourful, auditory, and synesthetic learning…
BitDogLab Panel SMD version bill of materials (BOM)
11 components, 9 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 2 | Conn_01x05_Pin | PinHeader_1x05_P2.54mm_Vertical | J2, J9 |
| 2 | GND | SolderWire-2sqmm_1x02_P7.8mm_D2mm_OD3.9mm | J3, J5 |
| 1 | ANA-IN | SolderWire-2sqmm_1x02_P7.8mm_D2mm_OD3.9mm | J4 |
| 1 | 3V3 | SolderWire-2sqmm_1x02_P7.8mm_D2mm_OD3.9mm | J6 |
| 1 | 5V-VSYS | SolderWire-2sqmm_1x02_P7.8mm_D2mm_OD3.9mm | J7 |
| 1 | 0 | SolderWire-2sqmm_1x02_P7.8mm_D2mm_OD3.9mm | J10 |
| 1 | 1 | SolderWire-2sqmm_1x02_P7.8mm_D2mm_OD3.9mm | J11 |
| 1 | 2 | SolderWire-2sqmm_1x02_P7.8mm_D2mm_OD3.9mm | J12 |
| 1 | 3 | SolderWire-2sqmm_1x02_P7.8mm_D2mm_OD3.9mm | J13 |
BitDogLab Panel SMD version design files
The KiCad project lives in the BitDogLab-Escola4-0/MicroPython repository on GitHub; these links point at the commit this page was built from.
BitDogLab Panel SMD version: common questions
How big is the BitDogLab Panel SMD version PCB?
The BitDogLab Panel SMD version measures 87.9 × 23.1 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the BitDogLab Panel SMD version?
11 components, from 9 distinct parts. The full bill of materials is listed on this page.
Where can I download the BitDogLab Panel SMD version design files?
From the BitDogLab-Escola4-0/MicroPython repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.
Can I use the BitDogLab Panel SMD version design in my own project?
The repository has no license, so all rights stay with BitDogLab-Escola4-0. Use it as a reference, and ask the author before reusing the design.
