Pmod Debug
About the Pmod Debug PCB
Pmod Debug is an open source PCB design by ciniml, published on GitHub under the CC-BY-4.0 license. It is a 2-layer board measuring 17.8 × 32.1 mm, with 3 components from 3 distinct parts.
From the project
Extension boards for Tang series FPGA boards
Sipeedが製造・販売している、Tang Nano 9K, Tang Nano 20K およびTang Primer 20K向けのベースボードおよび拡張基板の設計データです。
Pmod Debug bill of materials (BOM)
3 components, 3 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | Conn_02x06_Top_Bottom | Conn_Pmod_Spec_B_Thin | J1 |
| 1 | Conn_02x06_Top_Bottom | Conn_Pmod_Spec_D_Vertical_Thin | J2 |
| 1 | Conn_02x06_Top_Bottom | Conn_Pmod_Spec_D_Thin | J3 |
Pmod Debug design files
The KiCad project lives in the ciniml/TangFPGAExtensions repository on GitHub; these links point at the commit this page was built from.
- LayoutPmod_Debug.kicad_pcb
- SchematicPmod_Debug.kicad_sch
Pmod Debug: common questions
How big is the Pmod Debug PCB?
The Pmod Debug measures 17.8 × 32.1 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Pmod Debug?
3 components, from 3 distinct parts. The full bill of materials is listed on this page.
Where can I download the Pmod Debug design files?
From the ciniml/TangFPGAExtensions repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.
Can I use the Pmod Debug design in my own project?
Yes, under the terms of its CC-BY-4.0 license, which ciniml chose for the repository.
