OrthusTrackpad
About the OrthusTrackpad PCB
OrthusTrackpad is an open source PCB design by Hob-dev, published on GitHub. It is a 2-layer board measuring 36.4 × 36.4 mm, with 12 components from 6 distinct parts.
Other key parts include the IQS7211E001QNR. By type, the board carries 7 capacitors, 3 resistors, 1 IC and 1 connector.
It belongs with the keyboards designs in this gallery.
From the project
The trackpad for the Orthus split keyboard. Easily modifiable+ good resource for trackpad design.
A capacitive trackpad PCB designed as a component of the Orthus split keyboard, but also usable as a standalone mutual-capacitance touch sensor.
The PCB carries a diamond-pattern mutual-capacitance sensor grid intended to be paired with a touch controller IC and read over I²C. The grill cutout in Fabrication/ matches the sensor pitch and is meant to be laser/CNC-cut from a thin overlay.
Main components on the OrthusTrackpad
OrthusTrackpad bill of materials (BOM)
12 components, 6 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | IQS7211E001QNR | UQFN-20_L3.0-W3.0-P0.40-BL-EP1.7 | U1 |
| 1 | CONN_01X06 Conn_01x06 | FPC-SMD_6P-P0.50_XUNPU_FPC-05F-6PH15 | J1 |
| 3 | 100PF 100pF | C_0402_1005Metric | C1, C3, C5 |
| 3 | 2.2UF 2.2uF | C_0402_1005Metric | C2, C4, C6 |
| 1 | 100NF 100nF | C_0402_1005Metric | C7 |
| 3 | 4.7K 4.7k | R_0603_1608Metric | R1, R2, R3 |
OrthusTrackpad design files
The KiCad project lives in the Hob-dev/OrthusTrackpad repository on GitHub; these links point at the commit this page was built from.
OrthusTrackpad: common questions
How big is the OrthusTrackpad PCB?
The OrthusTrackpad measures 36.4 × 36.4 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the OrthusTrackpad?
12 components, from 6 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the OrthusTrackpad design files?
From the Hob-dev/OrthusTrackpad repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.
Can I use the OrthusTrackpad design in my own project?
The repository has no license, so all rights stay with Hob-dev. Use it as a reference, and ask the author before reusing the design.
