Control

jamessa·Pragmatic·ControlR2/Control.kicad_pcb

Control PCB layout, top view — open source board by jamessa

About the Control PCB

Control is an open source PCB design by jamessa, published on GitHub under the MIT license. It is a 2-layer board measuring 25.4 × 33 mm, with 3 components from 2 distinct parts.

Other key parts include the ProMicro. By type, the board carries 2 connectors and 1 IC.

It belongs with the keyboards designs in this gallery.

From the project

A modular split keyboard kit.

Pragmatic 務實鍵盤 是一個分離式鍵盤套件,有數字列,有方向鍵與功能列。支援VIAL與QMK,輕鬆調整鍵盤配置,是分離式鍵盤的基本款。

本套件的開發將會務實的採用敏捷流程,每次都發佈最小可行硬體套件,然後讓大家一起討論,看看如何讓這個鍵盤變得更好用。

換言之,這將是一把大家一起設計的鍵盤,而設計的原則就是「 務實 」,只加入使用的功能,降低開發的時間與成本;使用最少的硬體,達到最好的效果。

在嘗試了超多款鍵盤與超級多的人體工學研究之後,上週我無意間試做了分離式鍵盤的始祖直排Let's split,不得了!!!這實在太好用了,務實,一整個好用。

首先直排讓手指可以自然的上下移動,減少手指的負擔,讓使用者不會過勞。分離式鍵盤可以顯著改善腰酸背痛的辦公室症候群。自己改用了分離式鍵盤以後,背痛就減輕八成(個人經驗)。

總鍵數達到72個,但是使用的空間卻比60%鍵盤還小,實在是太神奇了。因此我才會想要開啟這個專案。

Control, from the project README
From the project README

Main components on the Control

Control bill of materials (BOM)

3 components, 2 distinct parts.

QtyPartRefs
1
ProMicro
U1
2
Conn_02x04_Odd_Even
J1, J2

Control design files

The KiCad project lives in the jamessa/Pragmatic repository on GitHub; these links point at the commit this page was built from.

Control: common questions

How big is the Control PCB?

The Control measures 25.4 × 33 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Control?

3 components, from 2 distinct parts. The full bill of materials is listed on this page.

Where can I download the Control design files?

From the jamessa/Pragmatic repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the Control design in my own project?

Yes, under the terms of its MIT license, which jamessa chose for the repository.
