NeuroBytes NID Enclosed front only
About the NeuroBytes NID Enclosed front only PCB
NeuroBytes NID Enclosed front only is an open source PCB design by NeuroTinker, published on GitHub under the CC-BY-SA-4.0 license. It is a 2-layer board measuring 40.6 × 14.6 mm, with 10 components from 7 distinct parts.
By type, the board carries 4 diodes, 4 resistors and 2 connectors.
From the project
The Network Interface Device, or NID, is used to connect an Android tablet or phone to a NeuroBytes network, using UART and SWD depending on desired function. The NID hardware in conjunction with the NeuroBytes Network Explorer app performs a number of functions, including: recei
The Network Interface Device, or NID, is used to connect an Android tablet or phone to a NeuroBytes network, using UART and SWD depending on desired function. The NID hardware in conjunction with the NeuroBytes Network Explorer app performs a number of functions, including: receiving real-time membrane potential data from networked NeuroBytes boards and sending it to the Android tablet or phone, where it can be displayed and logged performing firmware updates on directly connected NeuroBytes boards changing parameters on networked NeuroBytes boards, such as dendritic weightings sending global…
NeuroBytes NID Enclosed front only bill of materials (BOM)
10 components, 7 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 2 | Conn_01x03_Female | ZF_CONN_FHDR_SMD_3 | J4, J6 |
| 1 | SML-P13PTT86R LED_POWER Rohm Semiconductor | ZF_SMD_NonPol_0402 | D1 |
| 1 | SML-P12WTT86R LED_NB Rohm Semiconductor | ZF_SMD_NonPol_0402 | D2 |
| 1 | SML-P12DTT86R LED_USB Rohm Semiconductor | ZF_SMD_NonPol_0402 | D3 |
| 1 | SML-P12VTT86R LED_PROG Rohm Semiconductor | ZF_SMD_NonPol_0402 | D4 |
| 1 | RC0402FR-07150RL R Yageo | ZF_SMD_NonPol_0402 | R11 |
| 3 | RC0402FR-071KL R Yageo | ZF_SMD_NonPol_0402 | R12, R13, R14 |
