Working new
About the Working new PCB
Working new is an open source PCB design by oomlout, published on GitHub. It is a 2-layer board measuring 30 × 30 mm, with 10 components from 3 distinct parts.
Working new bill of materials (BOM)
10 components, 3 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | hi14p_electronic_header_2d54_mm_4_pin | hi14p_electronic_header_2d54_mm_4_pin | J1 |
| 5 | MHM6 mhm6 | mhm6_electronic_mounting_hole_m6 | H1, H3, H5, H6, H9 |
| 4 | MHM3 mhm3 | mhm3_electronic_mounting_hole_m3 | H2, H4, H7, H8 |
Working new design files
The KiCad project lives in the oomlout/oomlout_oomp_module_src repository on GitHub; these links point at the commit this page was built from.
Working new: common questions
How big is the Working new PCB?
The Working new measures 30 × 30 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Working new?
10 components, from 3 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the Working new design files?
From the oomlout/oomlout_oomp_module_src repository on GitHub, which has the KiCad layout and the BOM; the links under Design files point to each one.
Can I use the Working new design in my own project?
The repository has no license, so all rights stay with oomlout. Use it as a reference, and ask the author before reusing the design.
