TriggerBoard Citrus
About the TriggerBoard Citrus PCB
TriggerBoard Citrus is an open source PCB design by plants-tech, published on GitHub under the CERN-OHL-S-2.0 license. It is a 2-layer board measuring 41.7 × 9.7 mm, with 6 components from 6 distinct parts.
By type, the board carries 2 connectors and 2 switches.
From the project
fork of a fork of phob 2.x (Phob 2.x Official -> PhloraGCC -> Zinnia)
fork of a fork of phob 2.x (Phob 2.x Official -> PhloraGCC -> ZinniaGCC)
USB D+/D- Pad Alignment with Model U GCC v2 Left Z implementation via its own pin; GPIO12 Start Pad edit; now in style of D-Pad B3f tactile switch thru-holes on ABXY pads Omron D2LS alignment thru-holes on ABXY pads (experimental) Revision of both Analog and C-Stick footprints; removal of t1/t2 thru-holes, conversion of t3 screw-holes from copper-lined pads to non-conductive thru-holes (screws work more effectively, stickbox "wobble" eliminated slightly)
TriggerBoard Citrus bill of materials (BOM)
6 components, 6 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | L | Pin_Header_Straight_1x02_Pitch2.54mm | J1 |
| 1 | R | Pin_Header_Straight_1x02_Pitch2.54mm | J2 |
| 1 | MouseBiteLA | breakaway-mousebites-double | H1 |
| 1 | MouseBiteRA | breakaway-mousebites-double | H2 |
| 1 | L | Trigger_Contact | SW1 |
| 1 | R | Trigger_Contact | SW2 |
TriggerBoard Citrus design files
The KiCad project lives in the plants-tech/Zinnia repository on GitHub; these links point at the commit this page was built from.
TriggerBoard Citrus: common questions
How big is the TriggerBoard Citrus PCB?
The TriggerBoard Citrus measures 41.7 × 9.7 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the TriggerBoard Citrus?
6 components, from 6 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the TriggerBoard Citrus design files?
From the plants-tech/Zinnia repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.
Can I use the TriggerBoard Citrus design in my own project?
Yes, under the terms of its CERN-OHL-S-2.0 license, which plants-tech chose for the repository.
