Shockboard

Shtaiven·restive-engines-keyboards·pcbs/shockboard_v1/shockboard.kicad_pcb

Shockboard PCB layout, top view — open source board by Shtaiven

About the Shockboard PCB

Shockboard is an open source PCB design by Shtaiven, published on GitHub under the MIT license. It is a 2-layer board measuring 282.9 × 126 mm, with 161 components from 8 distinct parts.

By type, the board carries 104 switches, 52 diodes, 2 LEDs, 1 IC and 1 transformer.

It belongs with the keyboards designs in this gallery.

From the project

Custom keyboards by restive.engines

This repository contains design and manufacturing files created by Steven Eisinger (@Shtaiven a.k.a. restive.engines). Everything you need to manufacture one of my keyboards can be found here, including pcbs, cases, and certain keycaps.

For keyboard firmware, please refer to my ZMK config repo.

Designed in 2024. Made to address shortcomings and enhance ergonomics of the shockboard. Ergonomic column staggered keyboard extendable with custom modules using terminal blocks or headers. 14 degree rotation on each half. Compatible with MX, Choc v1, and Choc v2 switches.

Shockboard, from the project README
From the project README

Shockboard bill of materials (BOM)

161 components, 8 distinct parts.

QtyPartRefs
1
—
MCU1
1
reset_switch_tht_top
RST1
52
—
S1, S2, S3, S4, S5, S6, S7, S8 +44
52
—
S53, S54, S55, S56, S57, S58, S59, S60 +44
1
—
T1
1
—
JST1
1
OLED
OLED1
52
—
D1, D2, D3, D4, D5, D6, D7, D8 +44

Shockboard design files

The KiCad project lives in the Shtaiven/restive-engines-keyboards repository on GitHub; these links point at the commit this page was built from.

Shockboard: common questions

How big is the Shockboard PCB?

The Shockboard measures 282.9 × 126 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Shockboard?

161 components, from 8 distinct parts. The full bill of materials is listed on this page.

Where can I download the Shockboard design files?

From the Shtaiven/restive-engines-keyboards repository on GitHub, which has the KiCad layout; the links under Design files point to each one.

Can I use the Shockboard design in my own project?

Yes, under the terms of its MIT license, which Shtaiven chose for the repository.
