Fpga routed with widths
About the Fpga routed with widths PCB
Fpga routed with widths is an open source PCB design by shyba, published on GitHub under the Custom license license. It is a 4-layer board measuring 42 × 27 mm, with 7 components from 4 distinct parts.
Other key parts include the FPGA. By type, the board carries 4 capacitors, 2 connectors and 1 IC.
From the project
A command-line PCB place & route tool.
Command-line PCB place & route tool with a Python API and a Mojo backend route path.
- Python-native board construction and routing workflows - CLI flows for build, place, route, drc, and repl - FreeRouting interop (freeroute) - Mojo backend routing (backend-route) using KiCad 9 in Docker for extract/apply
- Python 3.10+ - Docker (required for backend-route and freeroute) - KiCad on host is optional for backend-route/freeroute (Docker supplies KiCad 9 there) - System pcbnew is required for pardal-finalize
Main components on the Fpga routed with widths
Fpga routed with widths bill of materials (BOM)
7 components, 4 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | FPGA | TQFP-32_7x7mm_P0.8mm | U1 |
| 1 | JTAG | PinHeader_2x05_P1.27mm_Vertical | J1 |
| 1 | PWR | PinHeader_1x02_P2.54mm_Vertical | J2 |
| 4 | 100nF | C_0603_1608Metric | C1, C2, C3, C4 |
Fpga routed with widths design files
The KiCad project lives in the shyba/pardal repository on GitHub; these links point at the commit this page was built from.
Fpga routed with widths: common questions
How big is the Fpga routed with widths PCB?
The Fpga routed with widths measures 42 × 27 mm, has 4 copper layers and is 1.6 mm thick.
How many components are on the Fpga routed with widths?
7 components, from 4 distinct parts. The full bill of materials is listed on this page.
Where can I download the Fpga routed with widths design files?
From the shyba/pardal repository on GitHub, which has the KiCad layout; the links under Design files point to each one.
Can I use the Fpga routed with widths design in my own project?
It is published under Custom license, which limits how it may be reused; read the license before building on it.
