Multiout UFL
About the Multiout UFL PCB
Multiout UFL is an open source PCB design by ThunderTechnologies, published on GitHub under the CERN-OHL-W-2.0 license. It is a 2-layer board measuring 22 × 15.5 mm, with 3 components from 3 distinct parts.
From the project
An open source edge sharpener for the SNES
SNEdge V2 is to a state where it can be considered stable. As SNES revisions are tested, instructions will be added to the wiki. For now, only the full bypass is supported. The sidecar install will get a dedicated design at some point.
The SNEdge corrects much of the smearing that's present on the 2 chip SNES. It taps the console's RGB, cleanly buffers it, and applies a tuned amount of sharpening to bring back the crisp edges the stock 2 chip output loses.
Multiout UFL bill of materials (BOM)
3 components, 3 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | U.FL-R-SMT-1(10) R | U.FL_Hirose_U.FL-R-SMT-1_Vertical | J2 |
| 1 | U.FL-R-SMT-1(10) G | U.FL_Hirose_U.FL-R-SMT-1_Vertical | J3 |
| 1 | U.FL-R-SMT-1(10) B | U.FL_Hirose_U.FL-R-SMT-1_Vertical | J4 |
Multiout UFL design files
The KiCad project lives in the ThunderTechnologies/SNEdge repository on GitHub; these links point at the commit this page was built from.
Multiout UFL: common questions
How big is the Multiout UFL PCB?
The Multiout UFL measures 22 × 15.5 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Multiout UFL?
3 components, from 3 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the Multiout UFL design files?
From the ThunderTechnologies/SNEdge repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.
Can I use the Multiout UFL design in my own project?
Yes, under the terms of its CERN-OHL-W-2.0 license, which ThunderTechnologies chose for the repository.
