PicoTracker
About the PicoTracker PCB
PicoTracker is an open source PCB design by xiphonics, published on GitHub under the CC0-1.0 license. It is a 2-layer board measuring 76 × 64.5 mm, with 10 components from 10 distinct parts.
By type, the board carries 9 switches and 1 connector.
From the project
Buy the official kit at xiphonics store # Trademark Notice
Buy the official kit at xiphonics store # Trademark Notice
This repository contains the open-source hardware design files for the picoTracker project.
The hardware design files are released under the CC0 1.0 Universal license and may be used, modified, manufactured, and sold without restriction.
However, the picoTracker name, logos, product branding, and associated trademarks are not covered by the CC0 license and are not licensed for use by third parties.
PicoTracker bill of materials (BOM)
10 components, 10 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | C3650665 DF12NC(5.0)-20DP-0.5V(51) | Hirose_DF12_DF12E3.0-20DP-0.5V_2x10_P0.50mm_Vertical | J1 |
| 1 | C400229 LEFT | Cherry-MX-Low-Profile-kailh | SW3 |
| 1 | C400229 DOWN | Cherry-MX-Low-Profile-kailh | SW4 |
| 1 | C400229 RIGHT | Cherry-MX-Low-Profile-kailh | SW5 |
| 1 | C400229 UP | Cherry-MX-Low-Profile-kailh | SW6 |
| 1 | C400229 ALT | Cherry-MX-Low-Profile-kailh | SW7 |
| 1 | C400229 EDIT | Cherry-MX-Low-Profile-kailh | SW8 |
| 1 | C400229 ENTER | Cherry-MX-Low-Profile-kailh | SW9 |
| 1 | C400229 NAV | Cherry-MX-Low-Profile-kailh | SW10 |
| 1 | C400229 PLAY | Cherry-MX-Low-Profile-kailh | SW11 |
PicoTracker design files
The KiCad project lives in the xiphonics/picoTracker-pcb repository on GitHub; these links point at the commit this page was built from.
PicoTracker: common questions
How big is the PicoTracker PCB?
The PicoTracker measures 76 × 64.5 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the PicoTracker?
10 components, from 10 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the PicoTracker design files?
From the xiphonics/picoTracker-pcb repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.
Can I use the PicoTracker design in my own project?
Yes, under the terms of its CC0-1.0 license, which xiphonics chose for the repository.
