BF-018A Panel12
About the BF-018A Panel12 PCB
BF-018A Panel12 is an open source PCB design by botanicfields, published on GitHub under the CC0-1.0 license. It is a 2-layer board measuring 195.6 × 170.2 mm, with 19 components from 11 distinct parts.
Other key parts include the MCP6022 and M5ATOM. By type, the board carries 8 capacitors, 8 resistors, 2 ICs and 1 inductor.
From the project
My symbols, my footprints, my templates, etc. of KiCad6
Main components on the BF-018A Panel12
BF-018A Panel12 bill of materials (BOM)
19 components, 11 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | MCP6022 | SOIC-8_3.9x4.9mm_P1.27mm | U1 |
| 1 | M5ATOM M5Atom | BF@M5Atom | U2 |
| 1 | JJY_coil | BF@JJY_Coil | L1 |
| 1 | 100U 100u | CP_Elec_6.3x7.7 | C1 |
| 2 | 100N 100n | C_0603_1608Metric | C2, C8 |
| 4 | 10N 10n | C_0603_1608Metric | C3, C4, C5, C7 |
| 1 | 10U 10u | C_0603_1608Metric | C6 |
| 2 | 1k | R_0603_1608Metric | R1, R2 |
| 3 | 51K 51k | R_0603_1608Metric | R3, R4, R6 |
| 2 | 10K 10k | R_0603_1608Metric | R5, R7 |
| 1 | 510 | R_1206_3216Metric | R8 |
BF-018A Panel12 design files
The KiCad project lives in the botanicfields/KiCad6-Environment repository on GitHub; these links point at the commit this page was built from.
BF-018A Panel12: common questions
How big is the BF-018A Panel12 PCB?
The BF-018A Panel12 measures 195.6 × 170.2 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the BF-018A Panel12?
19 components, from 11 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the BF-018A Panel12 design files?
From the botanicfields/KiCad6-Environment repository on GitHub, which has the KiCad layout and the BOM; the links under Design files point to each one.
Can I use the BF-018A Panel12 design in my own project?
Yes, under the terms of its CC0-1.0 license, which botanicfields chose for the repository.
