Hexdump PCB layout, top view — open source STM32 board by brainsmoke
Simulate this board

About the Hexdump PCB

Hexdump is an open source STM32 PCB design by brainsmoke, published on GitHub. It is a 4-layer board measuring 25 × 447 mm, with 71 components from 9 distinct parts.

Its main chip is the STM32F030F4, from the STM32 family. Other key parts include the ICN3038, Houkem-5421-BSG, TC7258E and AP2204K-3.3. By type, the board carries 28 ICs, 25 capacitors, 15 resistors and 3 connectors.

It belongs with the displays & leds designs in this gallery.

From the project

quite a big hexdump display

Hexdump, from the project README
From the project README

Main components on the Hexdump

STM32F030F4ICN3038Houkem-5421-BSGTC7258EAP2204K-3.3

Hexdump bill of materials (BOM)

71 components, 9 distinct parts.

QtyPartRefs
1
STM32F030F4
IC1
8
ICN3038
U1, U4, U7, U10, U13, U16, U19, U22
16
Houkem-5421-BSG
U2, U3, U5, U6, U8, U9, U11, U12 +8
2
TC7258E
U25, U26
1
AP2204K-3.3
U27
3
Conn_01x07_Female
J1, J2, J3
14
C
C1, C2, C3, C4, C5, C6, C7, C8 +6
11
C
C14, C15, C16, C17, C18, C19, C20, C21 +3
15
R
R1, R2, R3, R4, R5, R6, R7, R8 +7

Hexdump design files

The KiCad project lives in the brainsmoke/hexboard repository on GitHub; these links point at the commit this page was built from.
