Elrocket

broskicodes·elrocket·PCBs/ion/v1/design_files/lulu_v1.kicad_pcb

Elrocket PCB layout, top view — open source STM32 board by broskicodes
Simulate this board

About the Elrocket PCB

Elrocket is an open source STM32 PCB design by broskicodes, published on GitHub. It is a 4-layer board measuring 36 × 64 mm, with 80 components from 49 distinct parts.

Its main chip is the ATSAMD21G18A-A, from the STM32 family. Other key parts include the LSM6DSV80, MCP1702X-330XXTT, W25Q16JVSS and DPS368XTSA1. By type, the board carries 36 capacitors, 26 resistors, 7 ICs, 3 diodes, 3 inductors and 2 transistors.

From the project

Open source designs and software for model rockets

Core changes include: - Different MCU - Added Bluetooth chip - Removed inputs for servos

Full write up describing changes coming soon.

Elrocket, from the project README
From the project README

Main components on the Elrocket

ATSAMD21G18A-ALSM6DSV80MCP1702X-330XXTTW25Q16JVSSDPS368XTSA1

Elrocket bill of materials (BOM)

80 components, 49 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
ATSAMD21G18A-A
STM32F405RGTx
U1
1
LSM6DSV80
nRF52810-QCxx
U2
1
MCP1702X-330XXTT
2450AT18D0100E
U3
1
MCP1702x-330xxTT
U4
1
W25Q16JVSS
U5
1
DPS368XTSA1
U8
1
LSM6DSV80
U9
2
NMOS
Q1, Q4
1
32.768KHZ
32MHz
Y1
1
8MHz
Y2
1
Screw_Terminal_01x04
PY1
1
D_TVS
D1
2
D_Schottky
D7, D8
2
600@100MHz
FB1, FB3
1
10UH
3.9nH
L1
6
100NF
100nF
C1, C11, C14, C17, C18, C24
4
1UF
100nF
C2, C7, C19, C21
1
4.7UF
100pF
C3
1
4.7UF
1uF
C4
3
10UF
100nF
C5, C22, C26
Show 29 more
QtyPartRefs
2
100NF
4.7uF
C6, C25
1
100NF
0.8pF
C8
2
100NF
6pF
C9, C10
1
20PF
100nF
C12
1
20PF
4.7uF
C13
2
100NF
20pF
C15, C16
1
4.7UF
100nF
C20
1
100NF
1uF
C23
1
100NF
10uF
C27
1
100UF
1uF
C28
1
1uF
C29
1
4.7uF
C30
5
100nF
C31, C32, C33, C35, C36
1
100uF
C34
2
5.1k
R1, R18
1
220
R2
1
5.1K
220
R3
1
5.1K
10k
R4
2
10K
10k
R5, R17
8
10k
R6, R7, R20, R22, R23, R24, R25, R26
1
10K
8.2k
R8
2
10K
100
R9, R10
1
10K
1.8k
R11
1
8.2k
R12
1
68
R13
1
220
68
R14
1
220
1.8k
R15
1
10K
39k
R16
2
22
R19, R21

Elrocket design files

The KiCad project lives in the broskicodes/elrocket repository on GitHub; these links point at the commit this page was built from.

Elrocket: common questions

What microcontroller does the Elrocket use?

The Elrocket is built around the ATSAMD21G18A-A, from the STM32 family.

How big is the Elrocket PCB?

The Elrocket measures 36 × 64 mm, has 4 copper layers and is 1.600198 mm thick.

How many components are on the Elrocket?

80 components, from 49 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Elrocket design files?

From the broskicodes/elrocket repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the Elrocket design in my own project?

The repository has no license, so all rights stay with broskicodes. Use it as a reference, and ask the author before reusing the design.

Can I test firmware for the Elrocket without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug STM32 firmware against it before you order a PCB.

Earlier revisions in the repo: lulu_v0
