Orangeclock s mini adapter

dsbaars·orangeclock-s-mini-adapter·orangeclock-adapter/orangeclock-adapter.kicad_pcb

Orangeclock s mini adapter PCB layout, top view — open source board by dsbaars
Simulate this board

About the Orangeclock s mini adapter PCB

Orangeclock s mini adapter is an open source PCB design by dsbaars, published on GitHub under the GPL-3.0 license. It is a 2-layer board measuring 34.8 × 30.2 mm, with 1 components from 1 distinct parts.

It belongs with the displays & leds designs in this gallery.

From the project

Source file for the adapter board, to make an OrangeClock out of a WeAct 2.9 inch display in combination with a S* mini.

Orangeclock s mini adapter, from the project README
From the project README

Orangeclock s mini adapter bill of materials (BOM)

1 components, 1 distinct parts.

QtyPartRefs
1
EPD
J1

Orangeclock s mini adapter design files

The KiCad project lives in the dsbaars/orangeclock-s-mini-adapter repository on GitHub; these links point at the commit this page was built from.

Orangeclock s mini adapter: common questions

How big is the Orangeclock s mini adapter PCB?

The Orangeclock s mini adapter measures 34.8 × 30.2 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Orangeclock s mini adapter?

1 components, from 1 distinct parts. The full bill of materials is listed on this page.

Where can I download the Orangeclock s mini adapter design files?

From the dsbaars/orangeclock-s-mini-adapter repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the Orangeclock s mini adapter design in my own project?

Yes, under the terms of its GPL-3.0 license, which dsbaars chose for the repository.
