Pal-2-kim adapter
About the Pal-2-kim adapter PCB
Pal-2-kim adapter is an open source PCB design by eduardocasino, published on GitHub under the MIT license. It is a 2-layer board measuring 21.7 × 112.9 mm, with 5 components from 5 distinct parts.
Other key parts include the LVC04. By type, the board carries 4 connectors and 1 IC.
From the project
KIM-1 Programmable Memory Board for the MTU Backplane
As well as for the PAL, the DECEN pin must be connected to pin K in the Application connector. You can do this using a clip probe.
Main components on the Pal-2-kim adapter
Pal-2-kim adapter bill of materials (BOM)
5 components, 5 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | LVC04 74LS32 | DIP-14_W7.62mm | U1 |
| 1 | Peripheral | PinSocket_2x22_P2.54mm_Horizontal | J1 |
| 1 | KIM-1 | KIM_EDGE | J2 |
| 1 | C711364 ~{RESET} | PinHeader_1x01_P2.54mm_Horizontal | J3 |
| 1 | Ext-~{DECEN} | PinHeader_1x01_P2.54mm_Vertical | J4 |
Pal-2-kim adapter design files
The KiCad project lives in the eduardocasino/kim-1-programmable-memory-card repository on GitHub; these links point at the commit this page was built from.
Pal-2-kim adapter: common questions
How big is the Pal-2-kim adapter PCB?
The Pal-2-kim adapter measures 21.7 × 112.9 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Pal-2-kim adapter?
5 components, from 5 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the Pal-2-kim adapter design files?
From the eduardocasino/kim-1-programmable-memory-card repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.
Can I use the Pal-2-kim adapter design in my own project?
Yes, under the terms of its MIT license, which eduardocasino chose for the repository.
