A5000 adapter PCB layout, top view — open source board by ep-infosec

About the A5000 adapter PCB

A5000 adapter is an open source PCB design by ep-infosec, published on GitHub under the Apache-2.0 license. It is a 2-layer board measuring 43.2 × 83.8 mm, with 9 components from 3 distinct parts.

Other key parts include the ROM header.

From the project

Adapter board to allow an "arcflash" A3000 ROM emulator to work on an A5000.

A5000 adapter, from the project README
From the project README

Main components on the A5000 adapter

ROM header

A5000 adapter bill of materials (BOM)

9 components, 3 distinct parts — part numbers from the project's BOM.

QtyPartRefs
4
ROM header
A3KROM1, A3KROM2, A3KROM3, A3KROM4
4
ROM header
A5KROM1, A5KROM2, A5KROM3, A5KROM4
1
—
A21
