Indicator
About the Indicator PCB
Indicator is an open source PCB design by FredM67, published on GitHub under the CC-BY-SA-4.0 license. It is a 2-layer board measuring 11.1 × 15 mm, with 3 components from 3 distinct parts.
By type, the board carries 1 connector, 1 diode and 1 resistor.
It belongs with the iot & wireless designs in this gallery.
From the project
Fichiers de conception KiCad pour le Mk2 PV Router — un système open-source de routage solaire photovoltaïque universel (monophasé, triphasé avec ou sans neutre, biphasé).
Fichiers de conception KiCad pour le Mk2 PV Router — un système open-source de routage solaire photovoltaïque universel (monophasé, triphasé avec ou sans neutre, biphasé).
Inspiré par www.mk2pvrouter.co.uk, ce projet fournit les schémas et circuits imprimés nécessaires pour construire un routeur PV capable de dévier l’excédent de production solaire vers des charges résistives (chauffe-eau, radiateurs, etc.).
Indicator bill of materials (BOM)
3 components, 3 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | LED | Molex_SL_171971-0002_1x02_P2.54mm_Vertical | J1 |
| 1 | LED | LED_D5.0mm | D1 |
| 1 | 1K | R_Axial_DIN0207_L6.3mm_D2.5mm_P10.16mm_Horizontal | R1 |
Indicator design files
The KiCad project lives in the FredM67/PVRouter-KiCad repository on GitHub; these links point at the commit this page was built from.
- LayoutIndicator/Indicator.kicad_pcb
- SchematicIndicator/Indicator.kicad_sch
Indicator: common questions
How big is the Indicator PCB?
The Indicator measures 11.1 × 15 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Indicator?
3 components, from 3 distinct parts. The full bill of materials is listed on this page.
Where can I download the Indicator design files?
From the FredM67/PVRouter-KiCad repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.
Can I use the Indicator design in my own project?
Yes, under the terms of its CC-BY-SA-4.0 license, which FredM67 chose for the repository.
