Right finger

geek-rabb1t·timothy·pcb/timothy_pcb/right-finger/right-finger.kicad_pcb

Right finger PCB layout, top view — open source board by geek-rabb1t
Simulate this board

About the Right finger PCB

Right finger is an open source PCB design by geek-rabb1t, published on GitHub under the MIT license. It is a 2-layer board measuring 137.6 × 114.7 mm, with 64 components from 5 distinct parts.

By type, the board carries 31 switches, 31 diodes and 2 connectors.

It belongs with the keyboards designs in this gallery.

From the project

Timothy is a tented split keyboard with lowered thumb cluster.

使いやすさを追求した左右分離型の自作キーボードキットです。 3Dプリント品のケースを採用することで市販品のような形状を実現しています。

キーボードキットや、半完成品は以下のサイトで販売しています。 カスタマイズしたり、ご自身で発注したい場合はこのリポジトリデータをご利用ください。

- キーボードキット： https://geek-rabb1t.booth.pm/items/4213539 - パームレスト： https://geek-rabb1t.booth.pm/items/4214631

case caseの3Dデータ doc ビルドガイド firmware ビルド済みのファームウェアや、各種設定データ gasket ガスケットのカッティングデータ palm-rest パームレストトップのカッティングデータ pcb PCBのデータ * plate スイッチプレートの外形データ

Right finger, from the project README
From the project README

Right finger bill of materials (BOM)

64 components, 5 distinct parts.

QtyPartRefs
1
Conn_01x06
J6
1
Conn_01x10
J8
30
Key_Switch_with_LED
SW32, SW33, SW34, SW35, SW36, SW37, SW38, SW39 +22
1
SW_Push
SW72
31
D
D37, D38, D39, D40, D41, D42, D43, D44 +23

Right finger design files

The KiCad project lives in the geek-rabb1t/timothy repository on GitHub; these links point at the commit this page was built from.

Right finger: common questions

How big is the Right finger PCB?

The Right finger measures 137.6 × 114.7 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Right finger?

64 components, from 5 distinct parts. The full bill of materials is listed on this page.

Where can I download the Right finger design files?

From the geek-rabb1t/timothy repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the Right finger design in my own project?

Yes, under the terms of its MIT license, which geek-rabb1t chose for the repository.
