BusinessCard
About the BusinessCard PCB
BusinessCard is an open source PCB design by JudasLilith, published on GitHub. It is a 2-layer board measuring 85.6 × 54 mm, with 5 components from 5 distinct parts.
Other key parts include the NT3H2111W0FHKH. By type, the board carries 1 IC, 1 diode, 1 inductor, 1 capacitor and 1 resistor.
From the project
Business card framework for pcb designs
A place for people to get started on making their own PCB business card!
Design originally from: https://jams.hackclub.com/jam/hacker-card
find some logos to place, or use the materials list to start new!
These are some Logos I added inside, but please acknowledge that I had to manually add a few lines when the imports for kicad was botched & the logos might look a bit different than expected. (All of the logos are in the nfcactual.pretty folder)
Main components on the BusinessCard
BusinessCard bill of materials (BOM)
5 components, 5 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | NT3H2111W0FHKH | QFN8P50_160X160X50L40X20N | U1 |
| 1 | LED | LED0805-R-RD | D1 |
| 1 | 10UH_5X5MM_1.0A 10uH_5x5mm_1.0A | 25X48MM_NFC_ANTENNA | L1 |
| 1 | C | CAPC1608X90N | C1 |
| 1 | R_1206 | C0603 | R1 |
BusinessCard design files
The KiCad project lives in the JudasLilith/BusinessCard repository on GitHub; these links point at the commit this page was built from.
BusinessCard: common questions
How big is the BusinessCard PCB?
The BusinessCard measures 85.6 × 54 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the BusinessCard?
5 components, from 5 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the BusinessCard design files?
From the JudasLilith/BusinessCard repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.
Can I use the BusinessCard design in my own project?
The repository has no license, so all rights stay with JudasLilith. Use it as a reference, and ask the author before reusing the design.
