Sub circ interface

laurapellizari·PBLE01---Hardware·sub_circ_interface/sub_circ_interface.kicad_pcb

Sub circ interface PCB layout, top view — open source board by laurapellizari

About the Sub circ interface PCB

Sub circ interface is an open source PCB design by laurapellizari, published on GitHub. It is a 2-layer board measuring 2.8 × 2.8 mm, with 19 components from 14 distinct parts.

Other key parts include the LM358DG. By type, the board carries 8 resistors, 4 connectors, 4 capacitors and 1 IC.

From the project

Embedded hardware design for learning

Sub circ interface, from the project README
From the project README

Main components on the Sub circ interface

LM358DG

Sub circ interface bill of materials (BOM)

19 components, 14 distinct parts.

QtyPartRefs
1
LM358DG
IC2
2
OSTTA024163
J6, J8
1
ALIM
J7
1
EXTENSÃO
J10
1
LM358DG
AMP_OP1
1
POT
RV1
2
100nF
C16, C20
2
220nF
C18, C19
2
4k3
R7, R11
2
8k2
R10, R12
1
1k
R13
1
3k3
R14
1
10k
R15
1
5k1
R16

Sub circ interface design files

The KiCad project lives in the laurapellizari/PBLE01---Hardware repository on GitHub; these links point at the commit this page was built from.

Sub circ interface: common questions

How big is the Sub circ interface PCB?

The Sub circ interface measures 2.8 × 2.8 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Sub circ interface?

19 components, from 14 distinct parts. The full bill of materials is listed on this page.

Where can I download the Sub circ interface design files?

From the laurapellizari/PBLE01---Hardware repository on GitHub, which has the KiCad layout; the links under Design files point to each one.

Can I use the Sub circ interface design in my own project?

The repository has no license, so all rights stay with laurapellizari. Use it as a reference, and ask the author before reusing the design.
