About the CHARGE SHUTDOWN PCB

CHARGE SHUTDOWN is an open source PCB design by luftaquila, published on GitHub. It is a 2-layer board measuring 135.6 × 90.4 mm, with 25 components from 18 distinct parts.

Other key parts include the ADJ14012. By type, the board carries 9 resistors, 7 diodes, 3 connectors, 2 ICs and 2 transistors.

From the project

E-Formula 전기시스템 회로도 및 PCB 설계도, 배선도

회로도 EV.kicadpro KiCAD 6.0 프로젝트 메인 회로도입니다. 추상적으로 차량의 모든 고전압/저전압 전기 계통이 표현되어 있습니다. 메인 회로도 하위의 계층 회로도는 개별 구성 요소를 추상화합니다. 계층 회로도 중 /PCB` 폴더 하위의 파일들은 실제 PCB의 회로도입니다.

PCB /PCB/\.kicadpcb KiCAD 6.0 PCB 아트워크 각 PCB 폴더는 하나의 독립적인 KiCAD 프로젝트입니다. 메인 회로도인 EV.kicadsch 파일이 계층 회로 구성을 통해 각 PCB 폴더의 .kicadsch 파일을 가리키는 방식으로 서로 연결되어 있습니다.

배선 wirings * 차량의 모든 외부 배선을 표현하는 WireViz 배선 체계도입니다.

CHARGE SHUTDOWN, from the project README
From the project README

Main components on the CHARGE SHUTDOWN

ADJ14012

CHARGE SHUTDOWN bill of materials (BOM)

25 components, 18 distinct parts — part numbers from the project's BOM.

QtyPartRefs
2
ADJ14012
U1, U2
1
IRF9540N
Q1
1
IRF740
Q2
1
PACK
J2
1
HV
J5
1
Conn_01x01_Female
J7
1
G2RL-1 12DC
G2RL-1_12DC
RELAY_DISCHARGE1
1
1k
R_DIS1
1
LV_ACTIVE
D1
1
SW_ACTIVE
D2
1
IMD_{COIL
D3
1
IMD_{FAULT
D4
1
BMS_{COIL
D5
1
BMS_{FAULT
D6
1
AIR_ACTIVE
D7
6
10k
R1, R2, R3, R4, R6, R7
1
240K
R5
2
10K
R8, R9

CHARGE SHUTDOWN design files

The KiCad project lives in the luftaquila/a-fa-schematics repository on GitHub; these links point at the commit this page was built from.

CHARGE SHUTDOWN: common questions

How big is the CHARGE SHUTDOWN PCB?

The CHARGE SHUTDOWN measures 135.6 × 90.4 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the CHARGE SHUTDOWN?

25 components, from 18 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the CHARGE SHUTDOWN design files?

From the luftaquila/a-fa-schematics repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the CHARGE SHUTDOWN design in my own project?

The repository has no license, so all rights stay with luftaquila. Use it as a reference, and ask the author before reusing the design.
