Sk6812-restaurant call pager
About the Sk6812-restaurant call pager PCB
Sk6812-restaurant call pager is an open source PCB design by manhoosbilli1, published on GitHub. It is a 2-layer board measuring 160 × 160 mm, with 16 components from 1 distinct parts.
It belongs with the displays & leds designs in this gallery.
From the project
Addressable SK6812MINI LED pager board for restaurant table-to-server alerts
Addressable SK6812MINI RGB LED pager - restaurant table-to-server call signal
- Status: Partial / WIP - Board size: 160 x 160 mm - Layers: 2 - Components: 16
- SK6812MINI x16+ (D1-D16) - addressable RGB LEDs in a single-wire daisy chain; one data line drives the entire string - Each LED carries its own driver + memory cell, so a single MCU GPIO can address each individually for animated patterns / per-table indicators
Sk6812-restaurant call pager bill of materials (BOM)
16 components, 1 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 16 | SK6812MINI | LED_SK6812MINI_PLCC4_3.5x3.5mm_P1.75mm | D1, D2, D3, D4, D5, D6, D7, D8 +8 |
Sk6812-restaurant call pager design files
The KiCad project lives in the manhoosbilli1/sk6812-restaurant-call-pager repository on GitHub; these links point at the commit this page was built from.
Sk6812-restaurant call pager: common questions
How big is the Sk6812-restaurant call pager PCB?
The Sk6812-restaurant call pager measures 160 × 160 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Sk6812-restaurant call pager?
16 components, from 1 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the Sk6812-restaurant call pager design files?
From the manhoosbilli1/sk6812-restaurant-call-pager repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.
Can I use the Sk6812-restaurant call pager design in my own project?
The repository has no license, so all rights stay with manhoosbilli1. Use it as a reference, and ask the author before reusing the design.
