About the Matosic macropad PCB

Matosic macropad is an open source PCB design by matosichrvoje, published on GitHub under the CC-BY-SA-4.0 license. It is a 2-layer board measuring 73 × 91 mm, with 44 components from 9 distinct parts.

Other key parts include the SeeeduinoXIAO. By type, the board carries 10 resistors, 9 switches, 9 diodes, 9 inductors, 4 connectors and 1 IC.

It belongs with the keyboards designs in this gallery.

From the project

Matosic Macropad — PCB + 3D case. Forked from anavi-macro-pad-10 (CC-BY-SA-4.0).

Open source programmable keypad with 9 mechanical switches and a clickable rotary encoder.

A derivative of ANAVI Macro Pad 10 by ANAVI Technology, redesigned around a Seeeduino XIAO module socket and migrated to KiCad 10. Released under the same Creative Commons Attribution-ShareAlike 4.0 International License (CC-BY-SA-4.0) as the upstream — see LICENSE.

- 9× Cherry MX (Kailh hot-swap sockets) wired as a 3×3 matrix with per-key 1N4148 anti-ghosting diodes - 1× clickable EC11 rotary encoder - Seeeduino XIAO module socket — supports any XIAO variant (XIAO RP2040 recommended). USB-C connector…

Matosic macropad, from the project README — From the project README

Main components on the Matosic macropad

Matosic macropad bill of materials (BOM)

44 components, 9 distinct parts — part numbers from the project's BOM.

Qty	Part	Footprint	Refs
1	SeeeduinoXIAO	Seeeduino XIAO-MOUDLE14P-2.54-21X17.8MM	U1
1	S8050	SOT-23	Q1
4	Conn_01x03_Male	LedConnector_1x03_P2.54mm	J1, J2, J3, J4
1	Rotary_Encoder_Switch	RotaryEncoder_Alps_EC11E-Switch_Vertical_H20mm	E1
9	SW_DIP_x01	Kailh_socket_MX	SW1, SW2, SW3, SW4, SW5, SW6, SW7, SW8 +1
9	1N4148	D_SOD-123	D1, D2, D3, D4, D5, D6, D7, D8 +1
9	LED	LED_1206_3216Metric	L1, L2, L3, L4, L5, L6, L7, L8 +1
9	68R	R_0603_HandSoldering	R1, R2, R3, R4, R5, R6, R7, R8 +1
1	470R	R_0603_HandSoldering	R10

Matosic macropad design files

The KiCad project lives in the matosichrvoje/matosic-macropad-pcb repository on GitHub; these links point at the commit this page was built from.

Matosic macropad: common questions

How big is the Matosic macropad PCB?

The Matosic macropad measures 73 × 91 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Matosic macropad?

44 components, from 9 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Matosic macropad design files?

From the matosichrvoje/matosic-macropad-pcb repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the Matosic macropad design in my own project?

Yes, under the terms of its CC-BY-SA-4.0 license, which matosichrvoje chose for the repository.
