QChord Dual GM Sound Bank Adapter
About the QChord Dual GM Sound Bank Adapter PCB
QChord Dual GM Sound Bank Adapter is an open source PCB design by partlyhuman, published on GitHub under the MIT license. It is a 2-layer board measuring 16 × 33.7 mm, with 4 components from 4 distinct parts.
Other key parts include the MX23C8100M and M29F160FB5AN6F2. By type, the board carries 2 ICs, 1 switch and 1 resistor.
From the project
Hardware and Software for the Suzuki Q-Chord
Things that work with the Suzuki QChord, primarily a reproduction QCard that can be built with completely off-the-shelf parts. These projects are under active development.
You can get one as long as stock lasts at my Ko-Fi shop!
A single cartridge that contains the entire Q-Card library, selectable by dip switches. The flash should be programmed prior to assembly, by concatenating the 4Mbit dumps you can find on archive.org.
Main components on the QChord Dual GM Sound Bank Adapter
QChord Dual GM Sound Bank Adapter bill of materials (BOM)
4 components, 4 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | MX23C8100M | PSOP-44_Castellated | U1 |
| 1 | M29F160FB5AN6F2 | Micron-M29F160FB5AN6F2-Manufacturer_Recommended | U2 |
| 1 | SW_DIP_x01 | SW_DIP_SPSTx01_Slide_9.78x4.72mm_W8.61mm_P2.54mm | SW1 |
| 1 | 100K | R_0805_2012Metric_Pad1.20x1.40mm_HandSolder | R1 |
