About the 2425 Projet2A Ingenuity PCB
2425 Projet2A Ingenuity is an open source STM32 PCB design by penelopehnr, published on GitHub. It is a 4-layer board measuring 65 × 30 mm, with 33 components from 18 distinct parts.
Its main chip is the STM32L412KBT6, from the STM32 family. Other key parts include the 173950536, BU33TD3WG-TR and LSM6DSMTR. By type, the board carries 11 capacitors, 7 resistors, 6 connectors, 4 ICs, 4 diodes and 1 switch.
From the project
- Pénélope HENNER - penelope.henner@ensea.fr - Kevin DUGARD - kevin.dugard@ensea.fr - Elio FLANDIN - elio.flandin@ensea.fr - Joel COLASO - joel.colaso@ensea.fr
- Pénélope HENNER - penelope.henner@ensea.fr - Kevin DUGARD - kevin.dugard@ensea.fr - Elio FLANDIN - elio.flandin@ensea.fr - Joel COLASO - joel.colaso@ensea.fr
Mars 2020 is a space mission to deploy the Perseverance rover on the Martian surface to study its surface and collect soil samples. It is the first of a series of three missions whose ultimate aim is to return these samples to Earth for analysis.

Main components on the 2425 Projet2A Ingenuity
2425 Projet2A Ingenuity bill of materials (BOM)
33 components, 18 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | 173950536 ~ | Buck_ing | U1 |
| 1 | STM32L412KBT6 STM32L412KBTx | LQFP-32_7x7mm_P0.8mm | U2 |
| 1 | BU33TD3WG-TR BU33TD3WG | SOT-23-5 | U3 |
| 1 | LSM6DSMTR LSM6DSM | LGA-14_3x2.5mm_P0.5mm_LayoutBorder3x4y | U4 |
| 1 | CONN_01X04 Conn_01x04 | JST_XH_B4B-XH-A_1x04_P2.50mm_Vertical | J1 |
| 1 | CONN_02X05_ODD_EVEN Conn_02x05_Odd_Even | PinHeader_2x05_P2.54mm_Vertical | J2 |
| 2 | CONN_01X03 Conn_01x03 | JST_XH_B3B-XH-A_1x03_P2.50mm_Vertical | J4, J5 |
| 1 | Conn_02x05_Odd_Even | PinHeader_2x05_P2.54mm_Vertical | J6 |
| 1 | CONN_ST_STDC14 Conn_ST_STDC14 | PinHeader_2x07_P1.27mm_Vertical_SMD | J8 |
| 1 | SW_Push | SW_Push_1P1T_NO_6x6mm_H9.5mm | SW2 |
| 4 | LED | LED_0603_1608Metric | D1, D3, D5, D6 |
| 1 | 10U 10u | C_0603_1608Metric | C1 |
| 7 | 100N 100n | C_0402_1005Metric | C2, C3, C4, C5, C7, C9, C11 |
| 1 | 4U7 4u7 | C_0402_1005Metric | C6 |
| 2 | 1u | C_0402_1005Metric | C8, C10 |
| 1 | 27K 27k | R_0402_1005Metric | R1 |
| 4 | 165 | R_0402_1005Metric | R2, R4, R6, R7 |
| 2 | 10K 10k | R_0402_1005Metric | R8, R9 |
2425 Projet2A Ingenuity design files
The KiCad project lives in the penelopehnr/2425_Projet2A_Ingenuity repository on GitHub; these links point at the commit this page was built from.
2425 Projet2A Ingenuity: common questions
What microcontroller does the 2425 Projet2A Ingenuity use?
The 2425 Projet2A Ingenuity is built around the STM32L412KBT6, from the STM32 family.
How big is the 2425 Projet2A Ingenuity PCB?
The 2425 Projet2A Ingenuity measures 65 × 30 mm, has 4 copper layers and is 1.6 mm thick.
How many components are on the 2425 Projet2A Ingenuity?
33 components, from 18 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the 2425 Projet2A Ingenuity design files?
From the penelopehnr/2425_Projet2A_Ingenuity repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.
Can I use the 2425 Projet2A Ingenuity design in my own project?
The repository has no license, so all rights stay with penelopehnr. Use it as a reference, and ask the author before reusing the design.
Can I test firmware for the 2425 Projet2A Ingenuity without the hardware?
Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug STM32 firmware against it before you order a PCB.
