Rotenso wifi mod v2-cardle
About the Rotenso wifi mod v2-cardle PCB
Rotenso wifi mod v2-cardle is an open source PCB design by saper-2, published on GitHub. It is a 2-layer board measuring 34 × 30 mm, with 12 components from 5 distinct parts.
By type, the board carries 7 test points, 2 jumpers and 1 connector.
It belongs with the iot & wireless designs in this gallery.
From the project
A replacement module for OSK103/OSK105 based on ESP8266 & esphome
This is basically a my version of Sergey's IoT-Uni-Dongle . I have created this for my Rotenso branded A/C (and any other A/C that take OSK103 or newer OSK105 wifi module).
E.g.: for hackers that got into manufacturer servers would be then simple to remotely upload firmware that would create encrypted tunnel from their server to inside my home network. Well, someone can say this won't happen, but I in last year, I read about chinese server hacked and that company stayed quiet about it, until stolen data made into black market and started popping up everywhere...
Rotenso wifi mod v2-cardle bill of materials (BOM)
12 components, 5 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | PROG | HDR1X07_V | J1 |
| 1 | PowerSel | HDR1X03_V | JP1 |
| 1 | 5V-ON | HDR1X02_V | JP2 |
| 2 | 3mm | MHOLE-3.2MM | MH1, MH3 |
| 7 | TP | PAD_SpingProbe_R50-2C | TP1, TP2, TP3, TP4, TP5, TP6, TP7 |
Rotenso wifi mod v2-cardle design files
The KiCad project lives in the saper-2/esp8266-osk103 repository on GitHub; these links point at the commit this page was built from.
Rotenso wifi mod v2-cardle: common questions
How big is the Rotenso wifi mod v2-cardle PCB?
The Rotenso wifi mod v2-cardle measures 34 × 30 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Rotenso wifi mod v2-cardle?
12 components, from 5 distinct parts. The full bill of materials is listed on this page.
Where can I download the Rotenso wifi mod v2-cardle design files?
From the saper-2/esp8266-osk103 repository on GitHub, which has the KiCad layout; the links under Design files point to each one.
Can I use the Rotenso wifi mod v2-cardle design in my own project?
The repository has no license, so all rights stay with saper-2. Use it as a reference, and ask the author before reusing the design.
