Heartbeat simulator

sasukeop108·heartbeat-simulator-pcb·PCB/Heart effect.kicad_pcb

Heartbeat simulator PCB layout, top view — open source board by sasukeop108

About the Heartbeat simulator PCB

Heartbeat simulator is an open source PCB design by sasukeop108, published on GitHub. It is a 2-layer board measuring 69.8 × 61.9 mm, with 19 components from 7 distinct parts.

Other key parts include the NE555P. By type, the board carries 11 diodes, 3 resistors, 2 capacitors, 1 IC and 1 transistor.

Heartbeat simulator, from the project README
From the project README

Main components on the Heartbeat simulator

Heartbeat simulator bill of materials (BOM)

19 components, 7 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
NE555P
U1
1
BC547
Q1
1
R_Potentiometer
RV1
11
LED
D1, D2, D3, D4, D5, D6, D7, D8 +3
1
C_Polarized
C1
1
C_Polarized
C2
3
R
R1, R2, R3

Heartbeat simulator design files

The KiCad project lives in the sasukeop108/heartbeat-simulator-pcb repository on GitHub; these links point at the commit this page was built from.

Heartbeat simulator: common questions

How big is the Heartbeat simulator PCB?

The Heartbeat simulator measures 69.8 × 61.9 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Heartbeat simulator?

19 components, from 7 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Heartbeat simulator design files?

From the sasukeop108/heartbeat-simulator-pcb repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.

Can I use the Heartbeat simulator design in my own project?

The repository has no license, so all rights stay with sasukeop108. Use it as a reference, and ask the author before reusing the design.
