MAP Card
About the MAP Card PCB
MAP Card is an open source PCB design by speeduino, published on GitHub. It is a 2-layer board measuring 19.8 × 15.9 mm, with 5 components from 5 distinct parts.
Other key parts include the MPXH6250AC6U. By type, the board carries 3 capacitors, 1 IC and 1 resistor.
From the project
Official Speeduino hardware designs
These resellers all contribute a portion of sales back to the project to allow for continued development to take place and we encourage sales through them whenever possible.
Of course, being open source, you are free to use the design files provided here to create your own hardware!
This project exists thanks to all the people who contribute, both in terms of code and testing provided. If you'd like to get involved, please have a read through Contributing and then jump on Discord to discuss things further
Main components on the MAP Card
MAP Card bill of materials (BOM)
5 components, 5 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | MPXH6250AC6U | MPXH6250AC6U | U1 |
| 1 | CC0805KRX7R9BB103 0.01uF | C_0805_2012Metric | C1 |
| 1 | CC0805KKX7R7BB105 1uF | C_0805_2012Metric | C2 |
| 1 | C0805C470J5GACAUTO 47pF | C_0805_2012Metric | C3 |
| 1 | RC0805FR-0751KL 51K | R_0805_2012Metric | R1 |
MAP Card design files
The KiCad project lives in the speeduino/Hardware repository on GitHub; these links point at the commit this page was built from.
MAP Card: common questions
How big is the MAP Card PCB?
The MAP Card measures 19.8 × 15.9 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the MAP Card?
5 components, from 5 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.
Where can I download the MAP Card design files?
From the speeduino/Hardware repository on GitHub, which has the KiCad layout, the schematic and the BOM; the links under Design files point to each one.
Can I use the MAP Card design in my own project?
The repository has no license, so all rights stay with speeduino. Use it as a reference, and ask the author before reusing the design.
