Taira bottom plate

strayer·taira-keyboard·plates/bottom/taira-bottom-plate.kicad_pcb

Taira bottom plate PCB layout, top view — open source board by strayer
Simulate this board

About the Taira bottom plate PCB

Taira bottom plate is an open source PCB design by strayer, published on GitHub under the MIT license. It is a 2-layer board measuring 151.5 × 121.2 mm, with 8 components from 1 distinct parts.

It belongs with the keyboards, iot & wireless and dev boards & breakouts designs in this gallery.

From the project

A wireless low-profile split mechanical keyboard with 66 keys inspired by the ErgoDash and Corne Chocolate

A wireless low-profile split mechanical keyboard with 66 keys inspired by the ErgoDash and Corne Chocolate. It runs ZMK on two nice!nanos, is fully wireless via Bluetooth and uses Kailh Choc V1 switches in a 18x19mm grid layout.

I used an ErgoDash with MX switches for over a year multiple hours each day. Even though I love typing on it, it always felt too bulky and the wires really started to annoy me - especially when moving between workplaces. At some point I discovered ZMK and started plans on building a keyboard based on the ErgoDash, but as low-profile as I could manage.

Taira bottom plate, from the project README
From the project README

Taira bottom plate bill of materials (BOM)

8 components, 1 distinct parts.

QtyPartRefs
8
MountingHole
H1, H2, H3, H4, H5, H6, H7, H8

Taira bottom plate design files

The KiCad project lives in the strayer/taira-keyboard repository on GitHub; these links point at the commit this page was built from.

Taira bottom plate: common questions

How big is the Taira bottom plate PCB?

The Taira bottom plate measures 151.5 × 121.2 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Taira bottom plate?

8 components, from 1 distinct parts. The full bill of materials is listed on this page.

Where can I download the Taira bottom plate design files?

From the strayer/taira-keyboard repository on GitHub, which has the KiCad layout; the links under Design files point to each one.

Can I use the Taira bottom plate design in my own project?

Yes, under the terms of its MIT license, which strayer chose for the repository.
