About the Pikey PCB

Pikey is an open source PCB design by SWITCHSCIENCE, published on GitHub. It is a 2-layer board measuring 189 × 56 mm, with 62 components from 4 distinct parts.

Other key parts include the ProMicro. By type, the board carries 30 diodes, 1 IC and 1 switch.

It belongs with the keyboards designs in this gallery.

From the project

This is 30 keys Keyboard and enclosure with integrated stand for Raspberry Pi 2,3,3+ and 3.5 inch display.

This is 30 keys Keyboard and enclosure with integrated stand for Raspberry Pi 2,3,3+ and 3.5 inch display.

PCB Gerber data KiCad project Schematic Artwork BOM Firmware QMK Keyboard source file Document Not yet. 3D model STL file * Tinkercad

Pikey, from the project README
From the project README

Main components on the Pikey

ProMicro

Pikey bill of materials (BOM)

62 components, 4 distinct parts — part numbers from the project's BOM.

QtyPartRefs
1
ProMicro
U1
30
keyswitch
MX1, MX2, MX3, MX4, MX5, MX6, MX7, MX8 +22
1
tactswitch
S1
30
diode
D1, D2, D3, D4, D5, D6, D7, D8 +22

Pikey design files

The KiCad project lives in the SWITCHSCIENCE/pikey repository on GitHub; these links point at the commit this page was built from.

Pikey: common questions

How big is the Pikey PCB?

The Pikey measures 189 × 56 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Pikey?

62 components, from 4 distinct parts, with part numbers taken from the project's own BOM. The full bill of materials is listed on this page.

Where can I download the Pikey design files?

From the SWITCHSCIENCE/pikey repository on GitHub, which has the KiCad layout and the BOM; the links under Design files point to each one.

Can I use the Pikey design in my own project?

The repository has no license, so all rights stay with SWITCHSCIENCE. Use it as a reference, and ask the author before reusing the design.
