UsbC2UsbA
About the UsbC2UsbA PCB
UsbC2UsbA is an open source PCB design by TheusHen, published on GitHub under the GPL-3.0 license. It is a 2-layer board measuring 63.2 × 30.6 mm, with 8 components from 7 distinct parts.
Other key parts include the USBLC6-2SC6. By type, the board carries 2 connectors, 2 resistors, 1 IC, 1 fuse, 1 inductor and 1 capacitor.
From the project
My first PCB: USB-C to USB-A adapter. A simple project for learning and warming up for Hack Club Highway 2026. Includes schematic, 3D view, and PCB design.
Main components on the UsbC2UsbA
UsbC2UsbA bill of materials (BOM)
8 components, 7 distinct parts — part numbers from the project's BOM.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | USBLC6-2SC6 | SOT-23-6 | U1 |
| 1 | USB_C_RECEPTACLE_USB2.0_14P USB_C_Receptacle_USB2.0_14P | USB_C_Receptacle_HRO_TYPE-C-31-M-12 | J1 |
| 1 | USB-AM-S-X-X-TH | SAMTEC_USB-AM-S-X-X-TH | J2 |
| 1 | Polyfuse | Fuse_Schurter_UMT250 | F1 |
| 1 | FerriteBead_Small | LairdTech_28C0236-0JW-10 | FB1 |
| 1 | C_Small | C_0603_1608Metric | C1 |
| 2 | 56K 56k | R_0603_1608Metric | R1, R2 |
