Bumwings plate top v001

tubbytwins·bumwings-kbd·v001/case/plate_top/bumwings_plate_top_v001.kicad_pcb

Bumwings plate top v001 PCB layout, top view — open source board by tubbytwins

About the Bumwings plate top v001 PCB

Bumwings plate top v001 is an open source PCB design by tubbytwins, published on GitHub under the MIT license. It is a 2-layer board measuring 369.9 × 133.2 mm, with 54 components from 2 distinct parts.

It belongs with the keyboards and iot & wireless designs in this gallery.

From the project

Ergonomic keyboard PCB design that uses the Waveshare RP2040-zero board.

I used JLCPCB to build the first prototype PCBs for this version. It works nicely.

See "info.md" for more information about the background and inspiration for this keyboard design.

"pcbcore52840" - 54-key hot-swap PCB based on the Waveshare Core52840 module "pcbrp2040zero" - 54-key hot-swap PCB based on Waveshare RP2040 "zero" controller "pcbxiao" - 54-key hot-swap PCB based on the Seeed Xiao controller "pcbxiao_s" - simplified 54-key direct-soldered PCB based on the Seeed Xiao controller

Bumwings plate top v001, from the project README
From the project README

Bumwings plate top v001 bill of materials (BOM)

54 components, 2 distinct parts.

QtyPartRefs
52
SW_PUSH
SW0, SW1, SW2, SW3, SW4, SW5, SW6, SW7 +44
2
SW_PUSH
SW23, SW35

Bumwings plate top v001 design files

The KiCad project lives in the tubbytwins/bumwings-kbd repository on GitHub; these links point at the commit this page was built from.

Bumwings plate top v001: common questions

How big is the Bumwings plate top v001 PCB?

The Bumwings plate top v001 measures 369.9 × 133.2 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Bumwings plate top v001?

54 components, from 2 distinct parts. The full bill of materials is listed on this page.

Where can I download the Bumwings plate top v001 design files?

From the tubbytwins/bumwings-kbd repository on GitHub, which has the KiCad layout; the links under Design files point to each one.

Can I use the Bumwings plate top v001 design in my own project?

Yes, under the terms of its MIT license, which tubbytwins chose for the repository.
