Curso
About the Curso PCB
Curso is an open source PCB design by xizuth, published on GitHub. It is a 2-layer board measuring 34.3 × 25.4 mm, with 7 components from 7 distinct parts.
Other key parts include the NE555. By type, the board carries 3 resistors, 1 IC, 1 connector, 1 diode and 1 capacitor.
From the project
Curso básico de kicad, armado de un oscilador Astable
Curso básico de Kicad desde el proceso de instalación hasta culminar con una PCB. Se desarrolla una PCB utilizando un NE555, construyendo un osculador Astable, desde la face de creación del esquemático hasta su terminanción en una PCB.
- 1. Instalación y prueba de kiCad en windows - 2. Creando esquemático en kicad - 3. Agregando más detalles a esquemático kicad - 4. Cómo exportar diagrama esquemático kicad - 5. Introducción a qué son los footprint - 6. Asignando footprint a componentes kicad - 7. Aprendiendo más sobre footprints y package de componentes electrónicos kicad - 8. Creando PCB…
Main components on the Curso
Curso bill of materials (BOM)
7 components, 7 distinct parts.
| Qty | Part | Footprint | Refs |
|---|---|---|---|
| 1 | NE555 | DIP-8_W7.62mm_LongPads | U1 |
| 1 | 5V | PinHeader_1x02_P2.54mm_Vertical | J1 |
| 1 | LED RED | LED_D5.0mm | D1 |
| 1 | 0.15uF | C_Disc_D4.3mm_W1.9mm_P5.00mm | C1 |
| 1 | 5k | R_Axial_DIN0309_L9.0mm_D3.2mm_P12.70mm_Horizontal | R1 |
| 1 | 3k | R_Axial_DIN0309_L9.0mm_D3.2mm_P12.70mm_Horizontal | R2 |
| 1 | 330 | R_Axial_DIN0309_L9.0mm_D3.2mm_P12.70mm_Horizontal | R3 |
Curso design files
The KiCad project lives in the xizuth/Curso-kicad repository on GitHub; these links point at the commit this page was built from.
- Layoutpractica1.kicad_pcb
Curso: common questions
How big is the Curso PCB?
The Curso measures 34.3 × 25.4 mm, has 2 copper layers and is 1.6 mm thick.
How many components are on the Curso?
7 components, from 7 distinct parts. The full bill of materials is listed on this page.
Where can I download the Curso design files?
From the xizuth/Curso-kicad repository on GitHub, which has the KiCad layout; the links under Design files point to each one.
Can I use the Curso design in my own project?
The repository has no license, so all rights stay with xizuth. Use it as a reference, and ask the author before reusing the design.
