Diypgs PCB layout, top view — open source AVR/Arduino board by 1r3n33

About the Diypgs PCB

Diypgs is an open source AVR/Arduino PCB design by 1r3n33, published on GitHub. It is a 2-layer board measuring 130 × 78 mm, with 14 components from 4 distinct parts.

Its main chip is the Arduino_Nano_Every, from the AVR/Arduino family. By type, the board carries 6 switches, 6 resistors, 1 module and 1 buzzer.

From the project

The DIY portable game system

Develop your own games with provided SDK and example!

If you are interested in getting one, please contact icaroulle+diypgs@gmail.com.

Diypgs, from the project README
From the project README

Main components on the Diypgs

Arduino_Nano_Every

Diypgs bill of materials (BOM)

14 components, 4 distinct parts.

QtyPartRefs
1
Arduino_Nano_Every
A1
1
Buzzer
BZ1
6
SW_Push_Dual
SW1, SW2, SW3, SW4, SW5, SW6
6
10K
R1, R2, R3, R4, R5, R6

Diypgs design files

The KiCad project lives in the 1r3n33/diypgs repository on GitHub; these links point at the commit this page was built from.

Diypgs: common questions

What microcontroller does the Diypgs use?

The Diypgs is built around the Arduino_Nano_Every, from the AVR/Arduino family.

How big is the Diypgs PCB?

The Diypgs measures 130 × 78 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Diypgs?

14 components, from 4 distinct parts. The full bill of materials is listed on this page.

Where can I download the Diypgs design files?

From the 1r3n33/diypgs repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the Diypgs design in my own project?

The repository has no license, so all rights stay with 1r3n33. Use it as a reference, and ask the author before reusing the design.

Can I test firmware for the Diypgs without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug AVR/Arduino firmware against it before you order a PCB.
