agekoda·phantomware·project files/phantomware/phantomware.kicad_pcb

Phantomware PCB layout, top view — open source board by agekoda

About the Phantomware PCB

Phantomware is an open source PCB design by agekoda, published on GitHub. It is a 2-layer board measuring 89.5 × 52.2 mm, with 37 components from 25 distinct parts.

By type, the board carries 19 resistors, 5 LEDs, 4 capacitors, 2 ICs, 2 transistors and 1 connector.

It belongs with the iot & wireless, power & battery and test & measurement designs in this gallery.

From the project

Phantomware is a fully custom-built multi-tool device based on the ESP32-S3, designed for wireless analysis, signal interaction, and hardware experimentation.

Phantomware is a fully custom-built multi-tool device based on the ESP32-S3, designed for wireless analysis, signal interaction, and hardware experimentation.

It combines RF, GPIO, IR, and NFC capabilities into a portable platform featuring a 240×320 TFT display, SD card storage, and a 3000mAh battery system with a full charging circuit, MAX17055 fuel gauge, and built-in overcharge and overcurrent protection.

Phantomware, from the project README
From the project README

Phantomware bill of materials (BOM)

37 components, 25 distinct parts.

QtyPartRefs
1
~
TPOWER(天源)
U3
1
~
ADI(亚德诺)
U5
1
DMN2058U
Q1
1
~
LRC(乐山无线电)
Q2
1
TF-15X15
J1
1
4kHz
S&S(海旭)
BUZZER1
1
~
VISHAY(威世)
IR_RX1
1
MCP9701AT-E/TT
MCP9701AT-E_TT
TEMP1
1
~
SHOU HAN(首韩)
USB1
3
VSMY14940
LED1, LED2, LED3
1
GREEN
LED4
1
RED
LED5
1
100nF
C1
2
10 uF
C2, C3
1
0.47 uF
C4
3
39
R1, R2, R3
2
10k
R4, R17
1
130
R5
1
10
R6
1
1.1k
R7
Show 5 more
QtyPartRefs
4
1k
R8, R15, R18, R19
1
10m
R9
2
4.7k
R10, R11
2
5.1k
R12, R13
2
560
R14, R16

Phantomware design files

The KiCad project lives in the agekoda/phantomware repository on GitHub; these links point at the commit this page was built from.

Phantomware: common questions

How big is the Phantomware PCB?

The Phantomware measures 89.5 × 52.2 mm, has 2 copper layers and is 1.6 mm thick.

How many components are on the Phantomware?

37 components, from 25 distinct parts. The full bill of materials is listed on this page.

Where can I download the Phantomware design files?

From the agekoda/phantomware repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the Phantomware design in my own project?

The repository has no license, so all rights stay with agekoda. Use it as a reference, and ask the author before reusing the design.
