PCB v1

chaxaf·Supersonic-Test-Rocket·hardware/main_pcb/PCB_v1.kicad_pcb

PCB v1 layout, top view — open source NXP board by chaxaf

About the PCB v1

PCB v1 is an open source NXP PCB design by chaxaf, published on GitHub. It is a 4-layer board measuring 140.8 × 32.1 mm, with 68 components from 39 distinct parts.

Its main chip is the Teensy3.5, from the NXP family. Other key parts include the MAX-7C-0, XB8X-DMUS-001, TSR 0.5-2433, 57202G5205LF and 1-2842102-0. By type, the board carries 24 resistors, 14 capacitors, 12 ICs, 6 connectors, 4 diodes and 3 LEDs.

It belongs with the rf & radio, sensors and power & battery designs in this gallery.

From the project

Hardware for EPFL Rocket Team Hermes Supersonic Test Rocket

Semester project completed with the EPFL Rocket Team in 2022.

Hermes II is a compact avionics architecture developed for a small experimental rocket intended for validation flights and data generation. The project focused on redesigning the electronics of the original Hermes platform into a smaller, more modular system with telemetry, GPS, multiple sensor boards, and improved integration inside the rocket.

PCB v1, from the project README
From the project README

Main components on the PCB v1

MAX-7C-0XB8X-DMUS-001TSR 0.5-243357202G5205LF1-2842102-0Teensy3.53030switchADIS16470AIS1120SXTR

PCB v1 bill of materials (BOM)

68 components, 39 distinct parts.

QtyPartRefs
1
MAX-7C-0
IC1
1
XB8X-DMUS-001
IC2
1
TSR 0.5-2433
TSR_0.5-2433
IC4
2
57202G5205LF
U1, U2
1
1-2842102-0
U3
1
Teensy3.5
U4
1
3030
U5
2
switch
U6, U7
1
ADIS16470
U9
1
AIS1120SXTR
U10
1
MNMOS
M1
1
Altimax Power
J1
1
0878980304
J2
1
LiPo Connection
J3
1
CONUFL001-SMD-T
J4
1
57202G5203LF
J5
1
1734598-4
J7
1
MINIASMDC150F/12-2
MINIASMDC150F_12-2
F1
1
MISM7R610
SW3
1
TSR1-2450
VR1
Show 19 more
QtyPartRefs
3
150060GS75000
LED1, LED2, LED3
1
White LED
D1
1
Red LED
D2
1
D_Schottky
D3
1
BZX584C3V3-G3-08
D7
1
SMI-1027-T-5V-R
L3
8
100nF
C1, C2, C3, C5, C10, C11, C13, C14
3
10uF
C4, C9, C12
1
1uF +/- 10% 10V
C6
1
100nF +/- 10% 10V
C7
1
1uF
C8
7
10kΩ
R1, R4, R6, R11, R12, R13, R20
7
10K
R2, R9, R10, R14, R15, R16, R18
1
100Ω
R3
1
24Ω
R5
3
10kOhm
R7, R8, R27
2
?
R22, R23
2
24
R24, R25
1
R
R26

PCB v1 design files

The KiCad project lives in the chaxaf/Supersonic-Test-Rocket repository on GitHub; these links point at the commit this page was built from.

PCB v1: common questions

What microcontroller does the PCB v1 use?

The PCB v1 is built around the Teensy3.5, from the NXP family.

How big is the PCB v1?

The PCB v1 measures 140.8 × 32.1 mm, has 4 copper layers and is 1.6 mm thick.

How many components are on the PCB v1?

68 components, from 39 distinct parts. The full bill of materials is listed on this page.

Where can I download the PCB v1 design files?

From the chaxaf/Supersonic-Test-Rocket repository on GitHub, which has the KiCad layout and the schematic; the links under Design files point to each one.

Can I use the PCB v1 design in my own project?

The repository has no license, so all rights stay with chaxaf. Use it as a reference, and ask the author before reusing the design.

Can I test firmware for the PCB v1 without the hardware?

Yes. HardLabs builds a simulation of the board from its netlist and BOM, so you can run and debug NXP firmware against it before you order a PCB.
